TURFSTONE

The latticework design of Turfstone has long been a favorite of landscape architects and engineers for areas requiring supported turf and erosion control. Filled with grass or aggregates, Turfstone creates a permanent solution for emergency access areas, embankments, spillways, and environmentally sensitive parking lots.

Unilock Turfstone Unit
-
Unilock Turfstone Unit
-

TURFSTONE

The latticework design of Turfstone has long been a favorite of landscape architects and engineers for areas requiring supported turf and erosion control. Filled with grass or aggregates, Turfstone creates a permanent solution for emergency access areas, embankments, spillways, and environmentally sensitive parking lots.

Colors
Applications
Borders Accents e1632317158754
Borders and Accents
Heavy Dutty Vehicular e1632317142118
Commercial Vehicular
Light Duty Vehicular
Permeable 5 e1632317125337
Permeable
Roadways Streets e1632317106171
Residential Driveway
Pedestrian e1632317129849
Residential Pedestrian
Shape and size
STANDARD
400mm x 600mm x 80mm
15 3/4" x 23 5/8" x 3 1/8"
Technologies
Technologies
Classic

Classic

Classic Coat helps protect the surface texture and enhances the color of Classic products. For purchasers who prefer the look of a sealed project, these factory-sealed products save the time and expense of after-market sealing.

Our technologies
Colors
NATURAL
Pick a color
NATURAL
Information
Information
Packaging
Downloads

Turfstone

Turfstone has long been a favorite of landscape architects and engineers for areas requiring a supported turf. Its filigree design makes it an attractive and permanent solution for emergency access areas, embankments, spillways, and environmentally sensitive parking areas. Voids may be filled with grass or colored aggregates.

Recommended Base Stabilization – one layer of DriveGrid stabilization grid between subgrade and base material. Recommended depth 8” to 10” below pavers for maximum stability and performance. Use under Standard Base only.

Standard Base – Min. 6” – 8” of ¾” Crusher Run gravel (any road base standard in accordance with ASTM-D2940) compacted to 98% Standard Proctor Density (SPD).

Standard Bedding Course – 1” thick of course sand– in accordance with ASTM-D2940) screeded over base.

Jointing Material and Joint Stabilization

Fill all holes with topsoil to promote grass growth in openings.

Handling – This product is heavy and a two-man clamp is recommended for placement.

Edge Restraint - A concrete curb or a “sub-surface concrete wedge” can also be installed to retain the edge.

Paver Compaction - For the final compaction, a “rubber roller compactor” will give you the best results without breaking the block .

Cleaners – Not applicable

Sealers - Not applicable

Recommendation: Sealers – After the soil is placed in the openings, it is recommended to seed the area or fill with sod plugs. In order for the grass to establish, provisions must be made for watering. In dry areas, consider irrigation over this area to prevent turf burnout.

The Americans with Disabilities Act Accessibility Guidelines (ADAAG) provides measurable criteria to determine compliance, not individual product evaluation. Gaps, joints or openings, greater than ½” horizontal and ¼” vertical should be avoided as they can disrupt wheelchair maneuvering (United States Access Board – Guidelines and Standards).

Sq Ft per BundleSq Ft per LayerLayers per BundleUnits per Sq FtUnits per BundleUnits per LayerLbs per LayerLbs per BundleLbs per UnitSq Ft per Unit
STANDARD
Sq Ft per Bundle72.00
Sq Ft per Layer10.29
Layers per Bundle7
Units per Sq Ft0.39
Units per Bundle28
Units per Layer4
Lbs per Layer249.71
Lbs per Bundle1,747.94
Lbs per Unit62.43
Sq Ft per Unit2.57
